Technical Specification

ENGINE
Type Single Cylinder, 4 Stroke
Displacement
Bore x Stroke 57.3 x 57.8 mm
Ignition Type CDI
Starting Type kick/electrcic start
Max Power 14.5 HP @ 9500 rpm
Max Torque 12 N/m @ 8000 rpm
Mileage N/A
Compression Ratio 11:01
Cooling Liquid Cooled

BODY
Clutch Multiple wet
Chassis Diamond
Gear Box 5 Speed with Clutch
Number of Cylinder 1

BRAKE
Front Brake Disc
Rear Brake Drum

Wheeles & Tyre
Rim Size Front N/A
Rim Size Rear N/A
Tyre Size Front 110/90-16
Tyre Size Rear 140/90-15
Front
Rear

Electric
Battery
Head Light Bulb
Tail Light N/A
Signal Light N/A
Horn N/A

DIMENSION (mm)
Length(mm)
Width(mm)
Height(mm) 1390 mm
Wheel Base(mm)
Ground Clearance(mm) 150 mm
Dry weight(kg) 163 kg
Max. weight with Pay load (kg) 293 kg
Fuel Tank Capacity 18 L
