ENGINE
Type  Single cylinder 4 stroke air cooled
Displacement
Bore x Stroke  50 x 53
Ignition Type  CDI unit with advance variable and HT coil
Starting Type  Kick & Starter
Max Power  5.2 kw @ 7500 rpm
Max Torque  7 Nm @ 6500 rpm
Mileage
Compression Ratio  10:01
Cooling

BODY
Clutch
Chassis
Gear Box
Number of Cylinder

BRAKE
Front Brake  Disc
Rear Brake  Drum

Wheeles & Tyre
Rim Size Front
Rim Size Rear
Tyre Size Front  3.50-10
Tyre Size Rear  3.50-10
Front
Rear

Electric
Battery  12V 6AH ,MF Battery
Head Light  12V, 35/35W
Tail Light  12V, 5/21W
Signal Light  12V, 10Wx4
Horn  12 DC

DIMENSION (mm)
Length(mm)  1780
Width(mm)  770
Height(mm)  1230
Wheel Base(mm)  1270
Ground Clearance(mm)  150
Dry weight(kg)  100 KG
Max. weight with Pay load (kg)
Fuel Tank Capacity  5 Liter
