ENGINE
Type  Single Cylinder SOHC 4 Stroke Dual Valve, Air Cooled Petrol Engine
Displacement  110 CC
Bore x Stroke  52.4 x 49.5
Ignition Type  DCDI
Starting Type  Kick and Electric
Max Power  6.43 bhp @ 7500 rpm
Max Torque  7.0 kw @ 5500 rpm
Mileage  N/A
Compression Ratio  9.0 : 1
Cooling  Air Cooled

BODY
Clutch  Multiple wet
Chassis  Underbone
Gear Box  4 Forward, no reverse
Number of Cylinder  1

BRAKE
Front Brake  Disc (220 mm)
Rear Brake  Drum (110mm)

Wheeles & Tyre
Rim Size Front  N/A
Rim Size Rear  N/A
Tyre Size Front  2.50-17
Tyre Size Rear  2.75-17
Front  Hydraulic Telescopic
Rear  Coil spring Hydraulic

Electric
Battery  12V/5AH
Head Light  N/A
Tail Light  N/A
Signal Light  N/A
Horn  N/A

DIMENSION (mm)
Length(mm)  1900
Width(mm)  820
Height(mm)  1240
Wheel Base(mm)  1230
Ground Clearance(mm)  150
Dry weight(kg)  100 kg
Max. weight with Pay load (kg)  250 kg
Fuel Tank Capacity  4.8 Litres (Minimum)
