Memory Size
3 GB
Memory Type
GDDR5
Memory Bus
384 bit
Bandwidth
288.0 GB/s
Render Config
Shading Units
2048
TMUs
128
ROPs
32
Compute Units
32
L1 Cache
16 KB (per CU)
L2 Cache
768 KB
Theoretical Performance
Pixel Rate
32.00 GPixel/s
35.20 GPixel/s
Texture Rate
128.0 GTexel/s
140.8 GTexel/s
FP32 (float)
4.096 TFLOPS
4.506 TFLOPS
FP64 (double)
1,024 GFLOPS
1,126 GFLOPS (1:4)
Board Design
Slot Width
Dual-slot
Length
275 mm
308 mm
10.8 inches
12.1 inches
TDP
250 W
Suggested PSU
600 W
Outputs
2x DVI
1x HDMI 1.4a
1x DisplayPort 1.2
Power Connectors
1x 6-pin + 1x 8-pin
2x 8-pin
Board Number
C386
Graphics Features
DirectX
12 (11_1)
OpenGL
4.6
OpenCL
2.1 (1.2)
Vulkan
1.2.170
Shader Model
6.5 (5.1)
