Negotiable

                                            Product features

Feature


Description

Chipset


    Intel G31 Express

    Intel I/O Controller Hub 7 (ICH7)

Processors

Intel Core 2 Processors:

    Intel Core 2 Quad E9550 Processor (2.83 GHz, 12 MB L2 cache, 1333 MHz FSB)



Memory


1 GB DDR2 Synch DRAM PC2-6400 (800 MHz) Non-ECC (2 x 512 MB)

1 GB DDR2 Synch DRAM PC2-6400 (800 MHz) Non-ECC (1 x 1 GB)

Diskette Drive


1.44 MB Diskette Drive

Media Reader


HP 16-in-1 Media Reader and additional USB 2.0 port

Graphics


    Intel Graphics Media Accelerator 3100 – integrated

    NVIDIA GeForce 8400 GS (256 MB) Single Head PCIe x16 *

    ATI Radeon HD 2400XT (256 MB DH) PCIe x16

    note:

    * 1GB of system memory required. Graphics cards use part of the total system memory to enhance graphics performance.

Keyboard


Keys : 104, 105, 106, 107, 109 layout (depending upon country)

Dimensions (L x W x H): 18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)

Weight: 2 lb (0.9 kg) minimum

Pointing device


Touchpad with scroll zone, two pick buttons.

Expansion card slots


ExpressCard/54: Supports ExpressCard/54 and ExpressCard/34.

Optional Integrated Smart Card Reader (replaces ExpressCard/54 slot): Compatible with ISO 7816 compliant Smart Cards PC/SC interface support

Power Supply


250 W/300 W ATX Power Supply – PFC with a 115 v/230 v line switch (varies by country/region), with HV immunity up to 410 V/s
Communications

Features


Description

Integrated Realtek 8111C-VB-GR GbE Ethernet Controller


Connector: RJ45

Data rates supported : 2.5 GHz data rate with X1 link width.

Dimensions : 9 mm x 9 mm

Intel PRO/1000 PT Gigabit PCIe Controller


Connector: RJ45

Controller: Intel 82572EI Gigabit Ethernet Controller

Dimensions: 6.4 x 2.6 x 0.8 inches (16.3 x 6.6 x 1.9 cm)

Broadcom NetXtreme 5751 Gigabit Ethernet PCIe x1 Controller


Connector: RJ45

Controller: Broadcom 5751 PCI-Express LAN Controller

Power requirement: 3.1 W @ +3.3 V AUX supply with 5 V tolerance

Agere 56 K PCI Modem


Data Transmission 56,000 Kbps maximum downstream data

    note:

    56 Kbps technology refers to download speeds only and requires compatible modems at server sites. Other conditions may limit modem speed. FCC limitations allow a maximum of 53 Kbps during download transmissions.

Operating Temperature 32° degree to 158° degree F (0° degree to 70° degree C)

Operating Humidity: 20% to 90%, non-condensing

Chipset : Agere Systems SV92PL – Integrated PCI interface with 5 V tolerant buffers and CardBus support
Audio

Features


Description

Audio


    Realtek ALC662 High Definition audio codec

    3D audio compliant and HD Audio compatible

    Internal PC speaker (optional)

Power

Features


Description

Power Conservation


    APM 1.2 support

    Screen blanking

    Hard drive 'Idle' mode

    System Idle mode

    -3 Wpower consumption in ES mode – suspend to RAM (S3) (instantly available PC)

Physical specifications

Features


Description

Dimensions (H x W x D)
 Chassis Dimensions:

    15.16 x 7.28 x 16.38 inches with bezel, 385 x 185 x 416 mm

    14.88 x 6.50 x 16.10 inches without bezel, 378 x 165 x 409 mm

Packaged Dimensions (L x W x H): 19.63 x 24.13 x 10.56 inches 498.6 x 613 x 268.2 mm

Weight


18.3 lb (8.3 kg)

Temperature


Operating: 5° degree to 35° degree C

Non-operating: –30° degree to 65° degree C

Relative Humidity


Operating: 10% to 90%, (non-condensing at ambient)

Non-operating: 90% (non-condensing at ambient)

Maximum Altitude (unpres
