3D Printing Pen

Input Voltage: 100-240 V AC.
Temp: 160~230 Deg settable.
Filament: 1.75 mm PLA or ABS.
This 3D Pen is designed for the freehand drawing of 3-Dimensional objects
Adjustable output speed, temperature
Create projects horizontally or vertically

The 3D Printing Pen is used to draw and create is here, the 3D Printing Pen has arrived and is ready to kick-start your creative side.

As the 3D Pen draws, it extrudes heat plastic, which quickly cools and solidifies into a strong stable structure. This allows you to build an infinite variety of shapes and items with ease! Even in mid-air. Most people will instantly be able to trace objects on paper, and after only a few hours of practice, you will be able to make far more intricate objects.

What can I make with a 3D Pen? Pretty much anything; there are many ways the 3D Pen can be used. You can create flat forms and then peel it off the piece of paper, as freestyle 3D objects, or in separate parts, ready to be joined together using the 3D Pen. The creative opportunities are endless. Just google 3D pen for some great ideas and getting your creative juices flowing.

After the plastic filament his heated in the pen, the user simply moves the pen in any plane or direction to create a particular design. The filament then rapidly cools once it has been put into place, making sturdy objects capable of standing alone.

The product is being targeted at professionals such as architects and designers so they can quickly and efficiently make 3D models of their ideas and can alter the creation more easily than with a traditional 3D

Features :
This 3D Pen is designed for the freehand drawing of 3-Dimensional objects
0.7 mm Nozzle and Uses ABS 1.75mm ABS/PLA Material
Ergonomic design for optimum handling
Adjustable output speed, temperature
In many paint colors: filament is changed easily by pressing a button
LED indicator to check the operating temperature
Create projects horizontally or vertically
Embellish and personalize crafts or use to repair and modify 3D prints
Suitable for families and crafts

Specification:
Discharging Mode: Hot Melt Extrusion Molding
Molding: Three-Dimensional Molding
Print Range: Unlimited
Spinning Speed: Adjustable
Temperature :160 Degree - 230 Degree Adjustable
Working Voltage :12V 2A
The Nozzle Diameter: 0.4mm
Printing consumable items : 0.07--0.86 cm*3 /minute   adjustable
Printing Consumable Temperature : ABS 210 Degree   PLA 170 Degree
Melting temp of material : ABS-210C PLA-170C
Adapter current: 110/240V
Pen electric spec: DC 12V 2A 24w
The DC head diameter: 5.5mm*2.5mm
Net weight :62g

Design:

Power hole/feed empty: Personalized design, convenient operation.

Display: You can always view, adjust the temperature.

Step less speed change: With one hand to complete the adjustment, step-less speed.

Vents: Fan less design, quiet cooling, high efficiency.

Entrance / exit key: Side design, one-handed operation, simple and convenient .

Nib: Use the maximum temperature reached 60 °, will not cause burns, ease of use.

General Specification

Voltage(V) 100-240 (AC)
Temperature(°C) 160-230
Filament PLA/ABS
Filament Diameter (mm) 1.75
Length (mm) 220
Width (mm) 70
Weight(gm) 80
Shipment Weight 0.2 kg
Shipment Dimensions 22 × 5 × 5 cm

Package Includes :

1 x 3D Printing Pen.
6 x Random color filament (80g).
1 x Power adapter USB Cable
1 x User Manual and ideabook
